Zodiac C18(1)
Features alternative C18 carbon loading and end-capping to provide orthogonal selectivity, optimized for resolving closely eluting structural isomers.
Internal Diameter (mm)
Length (mm)
Particle Size (µm)
| Product Name | Internal Diameter (mm) | Length (mm) | Particle Size (µm) | Pore Size (Å) | Quantity | Add to Cart | Wishlist |
|---|---|---|---|---|---|---|---|
| Zodiac C18(1) : 100mm x 2.0mm,5um ZLS.C18(1).20.100.0519 | 2.0 | 100 | 5 | 190 |
|
||
| Zodiac C18(1) : 100mm x 3.0mm,5um ZLS.C18(1).30.100.0519 | 3.0 | 100 | 5 | 190 |
|
||
| Zodiac C18(1) : 100mm x 4.0mm,3um ZLS.C18(1).40.100.0319 | 4.0 | 100 | 3 | 190 |
|
||
| Zodiac C18(1) : 100mm x 4.0mm,5um ZLS.C18(1).40.100.0519 | 4.0 | 100 | 5 | 190 |
|
||
| Zodiac C18(1) : 100mm x 4.6mm,3um ZLS.C18(1).46.100.0319 | 4.6 | 100 | 3 | 190 |
|
No products found in this phase.
Orthogonal Selectivity and High Efficiency for Resolving Closely Eluting Structural Isomers.
Engineered with an alternative carbon load and proprietary end-capping. This phase provides orthogonal selectivity to standard C18 columns, making it optimal for resolving closely eluting structural isomers.
| USP Listing | L1 |
|---|---|
| Phase Type | Reverse Phase (RP) |
| Phase Ligand | C18(1) |
| Pore Size (Å) | 190 |
| Surface Area (m²/g) | 280 |
| Pore Volume (mL/g) | 1.1 |
| pH Range | 2-8 |
| Particle Size (µm) | 3,3.5,5,10 |
| Particle Technology | Fully Porous |
| Carbon Load (%) | 16% |
| End Capping | Yes |
| Max Temperature (°C) | 80 |
- Esomeprazole Magnesium Trihydrate USP Method On Zodiac C18(1)
- Aciclovir API EP Method on Zodiac C18(1)
- Co-amoxiclav EP Monograph on Zodiac C18(1)
- Tramadol Hydrochloride on Zodiac C18(1)
- Tramadol Hydrochloride on Zodiac C18(1)
- Benzoic acid Related Compounds Seperation using Zodiac C18(1)
- Mercaptopurine on Zodiac C18(1)
- Assay Of Alpha Lipoic Acid
- Allopurinol and It’s Related Compounds on Zodiac C18(1) Column
- DexLansoprazole Hydrochloride Jelly Analysis using Zodiac C18(1) Column
- Cefuroxime acid & 3-OH Cefuroxime acid Analysis using Zodiac C18(1) Column
- Palbociclib SST Analysis using Zodiac C18(1) Column
- Acidic Compounds
- Rabeprazole Sodium Hydrate RS USP Method on Zodiac
ZODIAC Catalogue 2026Download PDF
